Rod Breakdown Machine for Copper or Aluminum

See More Drawing Equipment

  • Basket Down Coiler for Copper and Aluminum

  • Medium Copper Wire Online Annealer

  • Electric Continuous Annealer for Thick Cu Wires

  • Catenary Contact Wire Drawing Machine

  • Multiwire Drawing Machine

  • Multimotor Rod Breakdown Machine

  • Medium Copper Wire Drawing Machine

  • Rod Breakdown Machine for Copper or Aluminum

  • Rod breakdown machine for copper or aluminum.
  • Single step capstans having each one its own drawing die.
  • Exchangeable long life tungsten carbide drawing rings.
  • Finishing capstan independently driven by AC servo motor, except for model DA-9.
  • HMI+PLC control system for drawing speed synchronization and die schedule auto arrangement.
  • Optionally supplied with all necessary accessories.
ModelDA-9DA-11DA-11DA-13DA-13
MaterialCuAlCuAlCu
No. of drafts911111313
Capstans Ø [mm]450450450450450
Inlet wire Ø [mm]8.09.58.09.58.0
Finished wire Ø [mm]2.2-4.72.0-5.01.8-4.21.6-4.61.35-4.0
Max. Speed [m/min]12001500150018001800
Machine area reduction [%]19.5-2419.5-2419.5-2419.5-2419.5-24
Main motor power [kW]250250250285285
Capstan motor power [kW]–5555/755555/75
Production capacity [kg/h]2800 (2.6mm wire at 1000 m/min)1000 (2.6mm wire at 1200 m/min)3200 (2.6mm wire at 1200 m/min)1000 (2.6mm wire at 1200 m/min)3200 (2.6mm wire at 1200 m/min)
